DB15 to IDC Ribbon Cable
DB15 to IDC flat ribbon cable assembly for interface adaptation, signal breakout, and equipment-side controller connection.
- DB15 to IDC mixed-end configuration
- Compact adapter harness structure
- Custom cable length available
- Suitable for equipment signal breakout
DB15 to IDC Ribbon Cable Overview
DB15 to IDC flat ribbon cable assembly for interface adaptation, signal breakout, and equipment-side controller connection.
This DB15 to IDC flat ribbon cable assembly is used where a 15-pin D-Sub interface needs to connect to an internal IDC flat-cable header. ENJOE supports DB15 to IDC assemblies with gray flat ribbon cable, common 10-34 pin IDC-side layouts, custom cable length, and project-based pin mapping for controller, programmer, fixture, and equipment interface applications.
DB15 to IDC mixed-end configuration
Compact adapter harness structure
Custom cable length available
Suitable for equipment signal breakout
Key Attributes
| Connector Format | DB15 to IDC socket |
|---|---|
| D-Sub Side | 15-pin D-Sub interface |
| IDC Side | 10-34 pin common, customized on request |
| Ribbon Cable Pitch | 1.27 mm flat ribbon cable common |
| Cable Gauge | 24-30 AWG common, 28 AWG widely used |
| Cable Type | Gray flat ribbon cable |
| Cable Length | 10 cm, 15 cm, 30 cm or customized |
| Pinout | As per drawing or request |
| Application | Controller adaptation, signal breakout, equipment interfaces |
Custom Options
OEM and project-based changes can be arranged according to your drawing, header layout, and packaging request.
DB15 shell and hardware selection
IDC-side pin count and layout
Custom cable length
Pin mapping as per request
Labeling and packaging
Common Applications
This cable type is commonly used in the applications below, depending on board layout, interface style, and installation space.
Industrial Automation & Control Systems
Machinery & Special Equipment
Quality Inspection
Each harness can be checked before shipment according to project requirements.
100% continuity and pin assignment test
Checked according to project requirements before shipment.
DB15 contact and shell orientation check
Checked according to project requirements before shipment.
IDC termination and strain relief inspection
Checked according to project requirements before shipment.
Cable routing and polarity confirmation
Checked according to project requirements before shipment.
Finished length check
Checked according to project requirements before shipment.
What We Need for Quotation
To review your project faster, please send the sourcing and technical details below.
- Drawing or sample photo
- Cable length and pin count
- Connector type or header layout
- Pinout or wiring sequence
- Application and installation position
- Working voltage / current if available
- Estimated order quantity
- Labeling, packing, or sampling requirements
Free Sample for Qualified B2B Projects
For real B2B projects with clear requirements, ENJOE can prepare one custom sample for evaluation. The customer covers the international shipping cost.
View Sample ProgramFrequently Asked Questions
Is the D-Sub side a standard 15-pin interface?
Yes. This product is based on the standard-density 15-pin D-Sub format commonly used for controller, programming, and signal-interface applications.
Can ENJOE build custom pin mapping for DB15 to IDC cables?
Yes. We can produce standard or custom pin mapping according to your wiring table, schematic, or approved sample.
Can the IDC side use different way counts?
Yes. Common IDC-side layouts can be arranged according to your board header and signal requirement instead of fixing one position count for every build.
Do you support different D-Sub hardware options?
Yes. We can review shell style, fixing hardware, strain relief, and any installation-space requirement before sampling.
What should we provide for an accurate quote?
Please send the DB15 gender, IDC-side position count, pin mapping, finished length, hardware requirement, expected quantity, and any labeling or package request.
More Products in This Category
Need a DB15 to IDC Adapter Cable?
Send the interface definition and pin mapping. We will confirm the suitable ribbon cable build.
